Large automatic film coating machine with vacuum chuck

Products Inquiry

Name * :

Tel * :

Email :

CompanyName :

Message :

Product Details

Large automatic film coating machine is widely used in various high temperature coating research, such as ceramic film, crystal film, battery material film, special nano film. Automatic coater uses a vacuum adsorption method to fix the substrate, so that the substrate is free from wrinkles during the coating process, thereby making the coating more uniform and smooth. The width of the film can be controlled according to the width of the film forming blade, and the baffle in the middle of the blade can be moved left and right. When the baffle and the side of the blade completely coincide, the film width reaches the limit.The length of the film can be controlled according to the stroke of the blade, and the limit stroke of the blade is 550 mm.

Large automatic film coating machine with vacuum chuck specifications:

Working voltage	Input: 24VDC A UL/CSA listed 100-240VAC IN - 24VDC OUT power adapter is included.
Max. Power Consumption	100W
Traverse Speed	●5-100 mm/sec variable ●Accuracy: 10mm/sec
Stroke Length	10-550 mm adjustable by using Adjustable Position Switch
Max. Coating Dimensions	250mm(W) x 550mm(L)
Vacuum chuck	●Vacuum chuck made of Aluminum alloy with <1 mm holes ●Vacuum Chuck Dimensions: 600mm(L) x 300mm(W) x 20mm(H)
Film Applicator	●One 250 mm width Micrometer Adjustable Film Applicator is included, with adjustable thickness from 0.01 mm - 5 mm ●Traverse Pusher is included for pushing the doctor blade to ensure constant speed coating ●Note: Thinnest film can be achieved is > 10 micron
Product Dimensions	805mm(L)×430mm(W)×223mm(H)
Net Weight	30 kg (67 lbs)
Warranty	One year limited warranty with lifetime support
