Product Details

The HS-SPC12-HP large-scale spin coater adopts a high-power servo motor and a high-precision driver to realize accurate spinning coating experiments on large-size samples. It can support samples up to 300mm in diameter and 2.3mm in thickness. And the speed resolution of the adopted high-precision drive can reach 0.2 rpm.

The chamber is made of stainless steel, which is beautiful and easy to clean, and has a locking device. After loading the sample, the chamber can be locked to prevent the sample from flying out in the event of an accident, which can effectively protect the user. In addition, the chamber has a built-in glue outlet for easy collection of waste liquid.

Technical parameters:

Model	HS-SPC12-HP
Chamber	Stainless steel; Support a diameter of 300mm and a thickness of 2.3mm; Built-in glue outlet
Spinning speed	≤3000rpm
Speed resolution	0.2rpm
Control mode	15 inch full HD touch screen with USB port upgrade program
Power supply	AC220V 50Hz 2kW
Vacuum pump	Oil-less vacuum pump, pumping120L/min
Vacuum interface	KF16
