Explosion-proof humidity analyzer

Products Inquiry

Name * :

Tel * :

Email :

CompanyName :

Message :

Product Details

Explosion-proof humidity analyzer can be used in medical research, tobacco companies, environmental testing, sewage treatment, petroleum and petrochemical, chemical plants, iron smelting. Humidity testing of factories, coal plants, garbage treatment plants, food processing, and safety protection of hazardous areas.
Explosion-proof humidity analyzer main features:
1. Integrated design, easy to install, reduce the impact of external interference on the measured value;
2. Original imported sensor can effectively guarantee the accuracy and service life of the instrument;
3. High-precision temperature automatic compensation to eliminate the influence of ambient temperature;
4. The extended function can be added to accurately measure the high temperature dew point value;
5. Two-stage filtration design to effectively filter dust and acidic liquids;
6. Probe 316F material, strong corrosion resistance;
7. Instrument housing protection class IP65;
8. Simple operation, long service life and easy maintenance;
9. Available in both absolute or relative humidity (please specify when ordering).

Explosion-proof humidity analyzer main features:

Measuring principle	capacitive / ceramic wet
Display mode	4-digit high-brightness LED display
Measuring range	Absolute humidity: 0 ~ 40.0% VOL Relative humidity: 0 ~ 100% RH (You can only display one mode at the same time, please explain when ordering)
Resolution	0.1%
Measurement accuracy	<±1.5% FS
Repeatability	<±1%
Response time	T₉₀<15S
Working temperature	Instrument: -10 ~ +50℃, probe 0 ~ 170℃
Sampling mode	plug-in
Analog output	4-20mA.DC (non-isolated output, load resistance less than 500 ohms) 2-way programmable dry contact passive alarm output, contact maximum capacity 220VAC/2A
Other interfaces	RS232 (default) or RS485
Power supply	AC220V±10% 50/60Hz, power consumption <15VA
Protection	316L probe, instrument housing protection class IP65
Explosion-proof grade	Exd IIB T6
Service life	instrument > 36 months, sensor > 24 months (under normal use conditions)
Sample gas component	no flammable gas, no strong corrosive gas
Probe length	regular 0.5m, 1.0m, 1.5m, other lengths can be customized (<1.8m)
Installation method	Plug-in, DN65 standard flange

Disclaimer: The product introduction content (including product images, product descriptions, technical parameters, etc.) of this site is for reference only. As the update may not be timely, there will be some differences between the content and the actual situation. Please contact our sales staff to confirm. The information provided on this site does not constitute any offer or promise, and the company will improve and modify any information on the website from time to time without prior notice.
