Compact Electric Jaw Crusher with Digital Size Control

Basic InfoModel NO.: HS-MSK-SFM-ALOMotor Type: DC MotorApplication: MetallurgyOutlet Size: 0.1-3mmCondition: NewJaw Plates: High Purity Alumina PlatesWarranty: 12 MonthsTrademark: HSSpecification: 90mm x 25mm loading portHS Code: 85141090Type: Jaw CrusherMotor Power: 500WMa

Products Inquiry

Name * :

Tel * :

Email :

CompanyName :

Message :

Product Details

Basic Info
Model NO.: HS-MSK-SFM-ALO
Motor Type: DC Motor
Application: Metallurgy
Outlet Size: 0.1-3mm
Condition: New
Jaw Plates: High Purity Alumina Plates
Warranty: 12 Months
Trademark: HS
Specification: 90mm x 25mm loading port
HS Code: 85141090
Type: Jaw Crusher
Motor Power: 500W
Materials: Fine Sandstone
Inlet Size: 5-40mm
Crushing Speed: 400 Times Per Minute
Timer: 0-60 Minutes
Certificate: Ce/TUV
Transport Package: Wooden Box
Origin: Zhengzhou, China

Product Description
Compact Electric Jaw Crusher with Digital Size Control -- MSK-SFM-ALO
Introduction
MSK-SFM-ALO is a compact electric jaw crusher with adjustable digital crushing size controller. Two jaw plates are made of high purity alumina to avoid metallic contamination while crushing materials. It is useful to break up sintered bulks prior to ball milling and saves the researcher labor and time.

Specification

Working Voltage	208 - 240VAC 50Hz, 500W
Crushing Speed	400 times per minute
Timer	0 to 60 minutes adjustable
Jaw Plates	Two high purity alumina plates Easy remove for cleaning. 90mm x 25mm loading port
Crushing Size	Input: Material Hardness must be < Mohs 8 Sample size: 5 - 20 mm diameter or thickness ~ 200 g of input materials can be added at once Output: Output size : 0.1 mm - 3 mm (adjustable via a digital micrometer). Crushing quantity: ~ 200 g is accepted by underneath drawer each time. Use a slide plate instead of the drawer, continuous output of samples can be achieved with continuous feeding of input materials.
Net Weight	150 lbs
Shipping Weight	185 lbs
Dimensions	L325mm×W500mm×H310mm
Compliance	CE certified
Warranty	Warranty
