| Electricity requirement |
110V AC or 220V AC selectable for universal use |
| Power Consumption |
200W |
| Current |
●Range: 0.5 - 5V programmable
●Accuracy: ±(0.05% of reading + 0.1% of range) |
| Data register conditions |
Time interval: 1 - 900s |
| Max. measurement cycles |
9999 cycles |
| Product Dimensions |
245mm(L) x 197mm(W) x 60mm(H) |
| Channels |
●The software (TC5.3) with calibration function is included to set various working modes for measuring capacity and lifecycle for all types of rechargeable batteries
●Working modes Include constant current discharge, constant current charge, constant voltage charge, constant resistance discharge, rest, cycles, etc.
●Limited threshold conditions include voltage, current, time, capacity, negative voltage slope, etc.
●With real-time monitoring windows and integrated graph/data windows, the testing process can be observed more directly and efficiently
●During the test, the software will provide instructions and warnings for assistance
●The calibration software can be used to calibrate the analyzer
●MS Excel 2013 30 days free trial is pre-installed for you to output the Excel data file. |
| Test Reports and Curves for analysis |
●8 alligator clips with cable for universal connecting
●8 spring load holders with adjustable length for measuring cylinder battery up to 70mm(H) |
| Laptop Computer |
●CE Certified |
| Warranty |
Two Year limited warranty with lifetime support for the battery analyzer. (Note: we do not carry warranty for the Laptops. In case service is needed for the laptops, please contact laptop manufacturer directly for warranty/non-warranty service.) |
| Application Notes |
●New buyers must buy the software installed laptop to avoid trouble from installation. If you like to run multiple battery analyzers on one Laptop, you can just buy multiple analyzers with one laptop which are offered at a discounted price.
●$500 will be deducted if one analyzer is purchased without the basic laptop.
●The customer can easily combine up to 20 battery analyzers (0.002-1mA, 0.1-10mA, 6mA-3000mA) by using normal Ethernet cable connector via one computer.
●You may order movable rack to organize the battery analyzers
●You may order internal resistance tester to measure DC resistivity |
| Net Weight |
11.5 kg (26 lbs) |
| Shipping Weight |
18 kg (40 lbs) / Analyzer only: 25lbs |
| Shipping Dimensions |
610mm(H) x 510mm(W) x 356mm(H) (24" x 20" x 14") |
